Using Tailscale with Docker 20 Jun 2020

Tailscale is a re­ally nice prod­uct that com­bines the mod­ern VPN ca­pa­bil­i­ties of Wireguard with a re­ally slick and well thought out user ex­pe­ri­ence.
I’ve been us­ing it for per­sonal pro­jects for a short while, and it feels like a tech­nol­ogy that I’ll be very happy to stick with over the long term.

It’s free for per­sonal use, very easy to use, and I’m con­fi­dent in its se­cu­rity, so I’d highly rec­om­mend it to oth­ers.

Background #

One thing I’ve been mean­ing to try for a while is ex­pos­ing a docker con­tainer over a Tailscale net­work. It’s easy to just run a con­tainer on a server ex­posed on a par­tic­u­lar host port, and then ac­cess that via Tailscale.

However, I’d pre­fer to ex­pose in­di­vid­ual Docker con­tain­ers rather than the en­tire host’s ser­vices. This way, we can ac­cess our con­tain­ers in a ‘host ag­nos­tic’ man­ner: we don’t need to think about where a con­tainer is run­ning or which of a host’s lim­ited ports be­longs to which con­tainer — it’s just there on our pri­vate net­work.

Solution #

The fol­low­ing docker-compose.yml file demon­strates one ap­proach, es­sen­tially set­ting up a Tailscale side­car con­tainer for our ser­vice:

version: "2.4"
services:
    tailscale:
        hostname: myservice                         # This will become the tailscale device name
        image: richnorth/tailscale:v0.99.1
        volumes:
            - "./tailscale_var_lib:/var/lib"        # State data will be stored in this directory
            - "/dev/net/tun:/dev/net/tun"           # Required for tailscale to work
        cap_add:                                    # Required for tailscale to work
          - net_admin
          - sys_module
        command: tailscaled

    myservice-container:
        image: nginx                                # Your image goes here
        network_mode: service:tailscale

Notice that we:

• start a Tailscale con­tainer, with the req­ui­site con­fig­u­ra­tion to al­low Tailscale to work in Docker.
• start our ser­vice con­tainer (the one we ac­tu­ally want ex­posed) along­side. We choose for this con­tainer to share a net­work name­space with the tailscale con­tainer — i.e. these con­tain­ers share a com­mon net­work in­ter­face.

After start­ing the pair of con­tain­ers, we need to au­then­ti­cate the Tailscale dae­mon with our Tailscale ac­count:

$ docker-compose up

...

$ docker-compose exec tailscale tailscale up


To authenticate, visit:

	https://login.tailscale.com/a/SOME_HEX_CODE

Tailscale gives us a lo­gin URL, which is used to au­then­ti­cate this new Dockerised Tailscale dae­mon to your pri­vate Tailscale ac­count.

After com­plet­ing lo­gin, Tailscale will store a small amount of state data in­side the tailscale_var_lib vol­ume-mounted di­rec­tory. This data needs to be re­tained be­tween restarts of the con­tain­ers to avoid hav­ing to re­peat the lo­gin process.

We can find the ser­vice’s Tailscale IP ad­dress via the ad­min con­sole:

If we were us­ing the nginx ex­am­ple ser­vice given above, we can now sim­ply ac­cess http://​SER­VICE_AD­DRESS from any de­vice con­nected to our Tailscale net­work. Notice that there’s no ex­plicit need to share the con­tain­er’s ports, and we can mi­grate this con­tainer + side­car to an­other host as long as we move the tailscale_var_lib di­rec­tory or per­form the Tailscale lo­gin step again.

And that’s it! Our ser­vice is just an­other server on our pri­vate Tailscale net­work, ready for use!

Followup thoughts #

• Running a VPN side­car con­tainer for every ser­vice process is not the most ef­fi­cient ap­proach from a mem­ory/​CPU per­spec­tive. Tailscale does seem to sip re­sources, but I’d like to see how it be­haves un­der heavy us­age.
• Obviously in this setup we can po­ten­tially have mul­ti­ple Tailscale in­stances on the same host, all of which lean on the same ker­nel’s Wireguard im­ple­men­ta­tion. I’ve not yet found ev­i­dence that this can be prob­lem­atic — it cer­tainly seems to at least work with 2+ in­stances. However, I’d be in­ter­ested to see if there are any lim­i­ta­tions which ap­ply when run­ning more con­tain­ers si­mul­ta­ne­ously.
• This so­lu­tion works for in­di­vid­ual one-off con­tain­ers, but for cases where many con­tain­ers need to be run, it’s more likely to be worth in­vest­ing time in cre­at­ing a Docker net­work that is fully routed through Wireguard. This post sug­gests such an ap­proach.
